Refractometers (pocket, bench and digital)

Hand refractometers
HR-110 Hand refractometer, 0-18% - Measuring range: 0-18% Brix - Resolution: 0.1% Brix (Sugar & mineral oils)

HR-120 Hand refractometer, 0-32% - Measuring range: 0-32% Brix - Resolution: 0.2% Brix (Sugar & mineral oils)

HR-130 Hand refractometer, 0-32% ATC - Measuring range: 0-32% Brix - Resolution: 0.2% Brix (Sugar)
With ATC - Compensation temperature range: 10°C-30°C

HR-140 Hand refractometer, 0-32% ATC, triple scale (Sugar)
Measuring range: 0-32% Brix, 0-140° OE (Oechsle), 0-40° Babo (KMN) - Resolution: 0.2% Brix, 1% OE, 0.2° Babo

HR-150 Hand refractometer, 0-80%, double scale. Measuring range: 0-80% Brix - Resolution: 1% Brix (sugar/Jam)

HR-160 Hand refractometer (Urine and Protein)
Measuring range: Serum Protein 0-12g/dl, Specific Gravity 1.000-1.050sg, Refractive Index: 1.330RI-1.360RI
Resolution: Serum Protein 0.2g/dl, Specific Gravity 0.005sg, Refractive Index 0.0005RI

HR-170 Hand refractometer, for battery, antifreeze
Measuring range: Ethylene Glycol -60°C (66.6%)-0°C (0%), Propylene Glycol, -50°C(62.4%)-0°C (0%)
Battery 1.100-1.400sg - Resolution: Ethylene Glycol 5°C, Propylene Glycol 5°C, Battery 0.01sg

HR-180 Hand refractometer (Wine and Grape)
Measuring range: Alcoholº 0-25% - Resolution: Alcoholº 0.2%
HR-190 Hand refractometer, 0-28%, for salinity - Measuring range: Salinity: 0-28%
Resolution: Salinity: 0.2% - With ATC - Compensation temperature range: 10°C-30°C

Bench Refractometer and Polarimeter

2-WAY - ABBE BENCH REFRACTOMETER

Main prism: horizontal Secondary prism: fitted on a hinge
Refraction index scale: Nd 1.300 – 1.700, Precision: Nd ± 0.0003, Division: Nd 0.0005
Sugars scale: 0-95% from Nd 1.300 – 1.530, Precision: 0-50% = 0.2%; 51-95% = 0.1%, Division: 0,25%
Thermometer scale: 0°C - 70°C, div. 1°C, Weight: 4 Kg Size: 140 x 100 x 235 mm

POL-1 BENCH POLARIMETER
Circular polarimeter using Nicol prisms, with monochrome light source
(589.3 Nm sodium bulb). Measurement range: ± 180°, Precision: 0.05% Division: 1°,
Magnification: 3x Eyepiece: with fine focusing, Stabilisation time: 5 mins. approx.
Polarimeter tubes: 100 mm and 200 mm, Size: 510 x 135 x 380 mm Power supply: 230V/50Hz, 30W

Replacement parts for POL-1 polarimeter:
POL-1.1 Sodium bulb
POL-1.2 100 mm polarimeter tube
POL-1.3 200 mm polarimeter tube

Digital Refractometers
HRD-300 Digital refractometer 0-45%, Brix Measuring range: 0-45% Brix Resolution: 0.1% Brix
Automatic Temperature Compensation Temperature range: 0-40°C, 32-104°F
Precision of temperature measurement: 1°C, 2°F Temperature resolution 0.1°C
Operation temperature0-35°C, 32-90°F Storage temperature: 0-50°C, 32-122°F
Dimension and weight: 185x59x45mm, 230g Power Supply: 1 battery 9v Alarm of Low Voltage

HRD-400 Digital refractometer 0-28%, (Salinity)
Measuring range: 0-28% Resolution: 0.1% - ATC Temperature range: 0-40°C, 32-104°F
Precision of temperature measurement: 1°C, 2°F - Temperature resolution 0.1°C
Operation temperature0-35°C, 32-90°F Storage temperature: 0-50°C, 32-122°F
Dimension and weight: 185x59x45mm, 230g Power Supply: 1 battery 9v

HRD-500 Digital refractometer (Urine, Serum and DI)
Urine SP.G 1.000-1.050, Serum P. 0-12g/dl, R.I. 1.3330-1.3900 Resolution: Urine SP.G 0.001, Serum P. 0.1g/dl,
Refractive Index 0.0001 Automatic Temperature Compensation Temperature range: 0-50°C, 32-122°F
Precision of temperature measurement: 1°C, 2°F Temperature resolution 0.1°C
Operation temperature 0-35°C, 32-90°F - Storage temperature: 0-50°C, 32-122°F
Dimension and weight: 185x59x45mm, 230g Power Supply: 1 battery 9v.
