Digital Imaging cameras (3 and 5 Mega pixel)

brochures and pdf’s available on request

Cameras are supplied with Optika Vision® Pro software, exclusively with the Optikam Pro series for professional image acquisition & analysis,
Software is also Microsoft VISTA O/S compatible.

OPTIKA VISION PRO software in detail

Download Optikam brochure (pdf)

OPTIKAM PRO digital imaging cameras

New cmos digital cameras from Optika - Image quality at this price is hard to beat!

Resolution 2048 x 1536 pixels (3.2 Mpixel)
Sensor : CMOS 1/2“
Pixel Size 3.2 ìm x 3.2 ìm
Imaging Area 6.55 mm x 4.92 mm
Frame Rate / Full Res 6 frames/sec
Frame Rate / Half Res 21 frames/sec
Optical Format 1/2”
Aspect Ratio 4:3
S/N Ratio 43 dB max
Dynamic Range 61 dB
ADC 10 bit
Data Output (Uncompressed Video) 3x8 bit
Exposure Range 0.2 -231 msec

Sensitivity 1.0 V/Lux-second
System Requirements Windows XP SP2 or later, USB 2.0 port
Software Optika Vision® software package, TWAIN interface
Capture Features Continuous auto white balance, continuous auto exposure, averaging, subsampling (decimation)
Included with the camera 3 m USB cable,
C-mount lens adaptor, adapter for stereomicroscope, C-mount cap,
76x24mm micrometric calibration slide,

Resolution 2560 x 1920 pixels (5.0 Mpixel)
Sensor : CMOS 1/1.8“
Pixel Size 2.77 ìm x 2.77 ìm
Imaging Area 7.33 mm x 5.44 mm
Frame Rate / Full Res 4 frames/sec
Frame Rate / Half Res 15 frames/sec
Optical Format 1/1.8”
Aspect Ratio 4:3
S/N Ratio 42 dB max
Dynamic Range 61 dB
ADC 10 bit
Data Output (Uncompressed Video) 3x8 bit
Exposure Range 0.125 -249.7 msec

Sensitivity 1.2 V/Lux-second
System Requirements Windows XP SP2 or later, USB 2.0 port
Software Optika Vision® software package, TWAIN interface
Capture Features Continuous auto white balance, continuous auto exposure, averaging, subsampling (decimation)
Included with the camera 3 m USB cable,
C-mount lens adaptor, adapter for stereomicroscope, C-mount cap,
76x24mm micrometric calibration slide,

Choice of 3 or 5 Megapixel cmos cameras
Easy to use,simple USB plug and play connection
C-mount system for video and still-image capturing at HIGH resolution.
Connects via trinocular, monocular or binocular heads of most microscopes
