EUROMEX MACROZOOM


  MonoZoom stand-alone digital microscope

• Zoom from 0.7x up to 5x

• 105 mm working distance

• 170 mm working distance with 0.5x lens

• Built-in incident LED ring light

• Built-in 1080p 2 MP HD camera

• HD 11.6 inch screen, -5° to 15° tilt

• Built-in mouse driven on-screen software

• Conveniently build-in capture button

• Removable 32 GB memory stick

• Metal stand




 C E N T R A L Z O O M O B J E C T I V E

The Digital MacroZoom MZ.5000 features a single zoom objective with a 0.7 to 5x zoom magnification. Zoom adjustment engravings on 1, 1.5, 2, 3, 4 and 5x. The working distance is 105 mm. Supplied with a 0.5x additional lens witha working distance of 170 mm


S TA N D

The Central Zoom Objective with attached screen and LED ring light is mounted on a rack and pinion system that sits on a large 320 x 260 mm metal stand. Travel range is 225 mm

I L L U M I N AT I O N

A supplied 5,500 K LED ring light with 56 LED’s can be mounted under the microscope body. The intensity is adjustable.


B U I LT- I N C A M E R A

Built-in HD 1080p high definition 2 MP CMOS high speed camera, 1920 x 1080 pixels, 60 fps with attached 11.6“ screen. The standard field of view is 29.8 to 4.18 and with the 0.5x additional lens from 59 to 8.35. The camera has one HDMI output that can be connected either to the attached screen or to an external HD screen


Two other USB ports accept the supplied 32 GB USB memory stick (up to 128 GB) and a supplied wireless mouse that drives the built-in on-screen software. The operator can also take and save images to the SD card by pressing on a capture button at the right side of microscope body
