Stylish yet sturdy - built-in camera port - infinity corrected optics - and great value!!
Designed with ease of use in mind.
Focus and XY controls are designed to allow the wrists to rest on the table.
Light intensity regulation is also placed within ease reach of the focusing knobs.
XY stage is fitted with a special glass insert that allows the user to readily identify the magnification of the optics below.
Innovative head design allows adjustment to compensate for operator height.
Complete with 10x and 20x phase contrast optics
Infinity corrected system, 45 mm parafocal (DIN)
22mm field of view eyepieces also accommodate spectacle wearers.
Trinocular head set at comfortable 30° inclined viewing angle, ( 360° rotating).
Interpupillary distance (48-75 mm) .Dioptric compensation. Ergonomic height adjustment.
5 position nosepiece
Long working distance Planachromat (LWD) infinity corrected (IOS) optics
4X/0.10 (WD 18 mm) .. 10X0.25 (WD 10 mm)* 20X/0.40 (WD 5.1 mm)* .
40X/0.60 (WD 2.6 mm) corrected for 1.2 mm coverslip .
* phase contrast optics
XY stage 250x230 mm. Movement 119x70 mm. Dropped controls for ease of use
Interchangeable metallic inserts for slides, Petri dishes and flasks.
Coarse and fine coaxial focusing and adjustable tension control.
Long working distance condenser, NA 0.30, working distance 72 mm.
Condenser can be removed to increase the working distance to 150 mm.
Field diaphragm, filter and phase ring holder.
12V/30W halogen bulb.
Only £1550.00 (ex vat)
20x and 40x phase contrast optics also available
|
